The 4MP10X Explosion Proof Anti-Corrosion PTZIR Dome IP Camera offers reliable, ATEX-certified surveillance for hazardous zones, integrating robust design and advanced imaging from leading explosion proof camera manufacturers and cctv supplier networks.
Advanced Surveillance for Hazardous Industrial Environments
Designed primarily for operators and engineers managing explosive or corrosive zones, this unit meets stringent requirements for continuous industrial surveillance. As a product from established explosion proof camera manufacturers, it enables secure, remote monitoring of critical areas with its anti-corrosion housing and ATEX certification, making it suitable for oil rigs, chemical plants, and offshore platforms. Integration with existing infrastructure is streamlined through standard protocols favored by cctv supplier programs, optimizing safety oversight in complex operational contexts with commercial surveillance cameras.
Robust Technical Performance and Detailed Specifications
Equipped with a 4MP CMOS sensor, the camera delivers sharp 2592×1944 resolution at 25fps, combined with a 10X motorized PTZ lens and 12X optical zoom, providing extensive coverage and detail. Its pan range of 0° to 355° and tilt from 0° to 90° support versatile positioning. IP68-rated anti-corrosion materials shield against harsh weather and chemical exposure while enabling day/night operation with IR up to 40 meters. Compliance with RTSP and ONVIF protocols allows seamless integration with surveillance camera systems and NVR/CMS solutions from security cameras wholesale providers for reliable, scalable monitoring setups.
Application in High-Risk Industrial Settings and Security Integration
This PTZIR Dome IP camera addresses the specific challenges faced in industries requiring explosion protection, including petrochemical and maritime sectors. Its design facilitates perimeter monitoring and risk management through features like alarm snapshots dispatch via email and FTP, which enhance operational response. Integration into broader surveillance camera systems enables centralized control and real-time data acquisition, enabling industrial clients and security cameras wholesale purchasers to maintain asset protection while adhering to strict safety standards and operational efficiency criteria.
Product Advantages
Structural and Design Excellence for Extreme Conditions
The camera’s explosion-proof housing is engineered with anti-corrosion materials that comply with ATEX directives, ensuring structural durability in hazardous environments. Its IP68 ingress protection and temperature tolerance range (-40°C to 60°C) support reliable operation under extreme weather and chemical exposure. This system's modular design permits straightforward integration into existing surveillance camera systems, allowing cctv supplier partners to deploy it in various industrial landscapes, thus maximizing protective measures while minimizing installation complexity.
Enhanced Operational Performance and User-Centric Features
With low power consumption options including 12 V DC and PoE, this solution offers efficient energy management critical for continuous operation. Remote control via P2P cloud service and mobile applications enhances operational flexibility, enabling surveillance from multiple locations. Features such as adaptive imaging (BLC, 3DNR, D-WDR) and automatic IR switching provide consistent, high-quality video output, adding to the value proposition for security cameras wholesale customers requiring dependable surveillance in explosive or corrosive environments.
| Camera | |
| Image Sensor: | 1/3'' Cmos Sensor |
| Signal System: | PAL/NTSC |
| Min. Illumination: | Color: 0.05lux @(F1.2, AGC ON), 0 lux with IR |
| Shutter Time: | 1/25 s to 1/10,000 s |
| Lens: | 10X 5-50mm Motor Lens(6~22mm Motor Lens Optional ) |
| Day&Night: | IR cut filter with auto switch |
| Image Enhancement: | BLC/3D DNR/D-WDR |
| Motion Detection | Support |
| Intelligent Detection(AI) | Human Detection |
| Privacy Protection | Support(4 Self-customized Areas) |
| Wather-Proof: | IP66 |
| Illumination for Infrared Switching: | 1~5Lux |
| Infrared Wavelength: | 850nm |
| Mimimum Illumination: | 0 Lux(IR ON) |
| IR Range: | 2PCS LEDS//35m IR |
| Compression Standard | |
| Video Compression: | H.265/H.264/MJPEG |
| Video Bit Rate: | 512Kbps~6144Kbps(main stream H.265) 64kbps~2048Kbps(sub stream H.265) |
| Audio Compression: | G711U/G711A |
| Dual Streams: | Yes |
| Triple Streams: | / |
| Image | |
| Max. Image Resolution: | 2592×1944(5MP)@25fps |
| Frame Rate: | 25fps(5MP).MAX main stream 25fps（D1) .MAX sub stream |
| Image Settings: | 3D NR, D-WDR, Image Flip, Saturation, Brightness, Contrast, Sharpness adjustable via client software, web browser or Smartphone App |
| Day/Night Switch: | EXT/Day/Night/Auto/Time |
| Audio | |
| Line IN/line OUT | Support（1ch） |
| Build-in MIC | Optional |
| Volnume adject | Yes |
| Network | |
| Network Protocols: | HTTP, TCP/IP, IPv4/v6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS,DDNS,IP Search(Support P2P, NVR, NVS etc.) |
| System Compatibility: | ONVIF(17.2 with profile S) |
| On-line Viewing | Max. Support 2 Users Simultaneously |
| Interface | |
| Communication Interface: | 1 RJ45 10M / 100M Ethernet Interface |
| RCA Audio Interface: | RCA Audio input/output Interface (Optional) |
| Alarm in/out interface： | Support（1ch） （Optional） |
| DC Power Plug: | DC Power Femate Interface |
| PTZ | |
| Angle | Pan:0~355° / Tilt:0~90° |
| speed | Pan: about 35°/s / Tilt: about 35°/s |
| preset | support 16 preset |
| General | |
| Operating Conditions: | -40 °C ~ 60 °C |
| Humidity 95% or less (non-condensing) | |
| Power Supply: | 12 V DC ± 10%/PoE(Optional) |
| Power Consumption: | 12 VDC ± 10%, Max Power Comsumption Less than 8W (When the infrared lamps turn on) |
| Weight: | 4KG |
| Verification to | BS EN62676-1-1-2014-Video surveillance systems for use in security applications |
Use Scenarios
Offshore Oil and Gas Platform Surveillance
In offshore oil and gas production, where explosion risks and corrosive conditions are prevalent, this explosion proof camera ensures comprehensive perimeter and facility monitoring. Its robust ATEX certification and IP68 rating allow it to withstand harsh marine environments, while the PTZ capability ensures wide area coverage essential for early incident detection. Integration with industrial surveillance camera systems facilitates centralized control and real-time alerts, supporting operational safety and minimizing personnel exposure to hazardous conditions, an asset frequently sought after by commercial surveillance cameras integrators.
Chemical Plant Hazardous Zone Monitoring
Chemical processing facilities require uncompromising surveillance solutions to detect leaks, fires, or unauthorized access without risk of ignition. This camera, as a product from reputable explosion proof camera manufacturers, fulfills this requirement with its explosion-proof certification and anti-corrosion materials. Its high-resolution imaging and 40-meter IR range enable 24/7 monitoring even in low-light conditions. Leveraging protocols like ONVIF, it integrates seamlessly into cctv supplier ecosystems, supporting proactive security management and compliance with industrial safety regulations through coordinated surveillance camera systems operation.
What certifications ensure the safety of your explosion-proof cameras?
Our cameras, including the 4MP10X Explosion Proof Anti-Corrosion PTZIR Dome IP Camera, are ATEX-certified, guaranteeing compliance with strict safety standards for hazardous environments. This certification ensures our explosion proof camera manufacturers deliver reliable security solutions for industrial sites.
Can you customize surveillance camera systems to fit specific industrial needs?
Yes, we offer ODM and OEM services allowing you to customize packaging, branding, logos, and even product molds. Our flexible production supports tailored surveillance camera systems designed to meet unique industrial requirements and site conditions.
What are the typical installation environments for your explosion-proof security cameras?
Our cameras are designed for harsh conditions such as chemical plants, offshore platforms, and oil rigs. Featuring IP68 protection and operating temperatures from -40°C to 60°C, they withstand corrosive atmospheres and extreme weather, ideal for continuous monitoring in hazardous industrial zones.
How do you handle shipping and logistics for large orders of security cameras wholesale?
We collaborate with international courier services like DHL, UPS, FedEx, and TNT to ensure timely delivery worldwide. Whether you place small or bulk orders of our security cameras wholesale, we strive to maintain efficient logistics and customer satisfaction throughout the shipping process.
