The 8MP22X Explosion Proof Anti-Corrosion PTZ IP Camera is a robust security camera designed for hazardous environments, offering advanced PTZ capabilities and high-resolution imaging for industrial applications. A trusted cctv supplier product.
Targeted Surveillance Solution for Hazardous Environments
The 8MP22X Explosion Proof Anti-Corrosion PTZ IP Camera is engineered specifically for industrial and hazardous site monitoring, meeting the stringent demands of safety-focused users such as petrochemical plants and offshore platforms. This ptz ip camera is optimized for real-time supervisory operations where durability and reliability are critical. Developed by experienced manufacturers, it serves security professionals requiring an explosion-proof, anti-corrosion solution that integrates seamlessly into existing security infrastructures. Its robust design ensures continuous operation under challenging environmental and regulatory conditions.
Precision Imaging and Advanced Technical Specifications
Equipped with an 8MP 1/1.8'' progressive scan CMOS sensor, this ptz camera delivers ultra-high-definition video up to 4K resolution with efficient H.265 encoding for reduced bandwidth usage. It provides 22x optical zoom with motorized autofocus and adjustable iris, enabling detailed image capture across variable lighting conditions. Capable of 360° horizontal and ±90° vertical rotation, it facilitates comprehensive area surveillance. The device holds IP68 and IK08 ratings for ingress and impact protection, supports -40°C to 60°C temperature operation, and complies with ATEX/IECEx explosion-proof standards, ensuring system reliability in strict hazardous zone classifications.
Integration and Applicability Across Critical Industries
As a high-performance security camera, this model finds application in chemical refineries, oil rigs, and maritime environments requiring corrosion-resistant monitoring solutions. Its compatibility with ONVIF and GB/T28181 protocols enables smooth integration into complex enterprise security management systems. The camera’s intelligent analytics—including face and license plate recognition, intrusion detection, and wide dynamic range—enhance situational awareness and operational efficiency, supporting incident prevention and post-event analysis in sectors emphasizing safety compliance and asset protection.
Product Advantages
Structural and Design Superiority for Demanding Environments
Constructed with stainless steel 316L housing, the 8MP22X combines explosion-proof certification with anti-corrosion properties tailored for extreme industrial settings. The modular design allows for flexible wall or column mounting options while maintaining a compact footprint at 436×296×406 mm. The system architecture supports POE+ or AC power inputs accommodating installation preferences. Comprehensive ingress protection (IP68) and impact resistance (IK08) ensure resilience against environmental stressors. Developed by a leading cctv supplier and refined by expert manufacturers, this ptz ip camera is built to comply with international explosion-proof standards, facilitating confident deployment in hazardous zones.
Operational Performance and User-Centric Capabilities
This model prioritizes optimized user experience through seamless remote control of its 360° horizontal and ±90° vertical PTZ movements with high precision and responsiveness. Intelligent video analytics reduce false alarms while providing actionable insights. Its triple video stream function supports simultaneous local recording, remote monitoring, and bandwidth-sensitive viewing. The camera’s day/night capabilities with automatic infrared filtering maintain critical visibility in diverse lighting conditions. Designed with industrial operational continuity in mind, this ptz camera offers advanced interface protocols and storage options, ensuring integration flexibility and value retention for security integrators and facility managers.
| Camera parameters | |
| Imaging device | 1/1.8'' progressive scan 8MP CMOS image sensor |
| Focus/Zoom | Focal length:6.5-143 mm 22x optical zoom |
| Zoom mode | Motorized zoom,autofocus |
| Iris | Auto/Manual,aperture range:F1.5-F3.4 |
| Shutter | Auto/Manual,Shutter Range:1-1/100000s |
| Minimum llumination |
0.03lux (F1.5,AGC ON,Color) |
| Olux(infrared enabled) | |
| WDR | Support |
| Day/night switching mode | Automaticinfrared filter switching from coloi to black |
| Video parameters | |
| Encoding protocol | H.265、H.264、MJPEG |
| Coding Standard | 4K(3840×2160)supports a maximum of 30 fps and 1080p(1920×1080)supports a maximum of 30fps |
| Video Streaming | Three-stream |
| OSD | Time OSD,custom OSD |
| Motion detection | Support |
| Private | Support |
| Storage | |
| Front-end storage | Micro SD up to 256GB |
| Backend storage | Dual-socket iSCSI direct block storage (used with the platform) |
| Intelligence | |
| Behavior detection | Cross-border detection,area intrusion detection,area entry detection,area exit detection,loitering detection,fast movement detection,crowd gathering detection,and parking detection Abandoned object detection and moving object detection |
| Anomaly detectior | Abnormal sound |
| Intelligent identification | Face detection,license plate recognition,and full intelligence detection |
| Statistical analysis | Passenger flow statistics |
| Interface Features | |
| Interface Type | One 36-pin FFC connector and one 6-pin connector (supporting the UART serial port function) |
| General | |
| Power | POE+/AC100V-240V etc optional,≤50W (The maximum power supply distance of POE+ is 80m.) |
| Dimensions(L*W*H) | 436*296*406mm |
| Net Weight | ≤26kg |
| Material | Stainless Steel 316L |
| Working Environment | -40℃~60℃,Humidity:≤100%RH(non-condensing) |
| Strorage Environment | -40℃~60℃,Humidity:s100%RH(non-condensing) |
| Surge Protection | 2KV |
| Ingress Protection | IP68 |
| Inlet Hole Specification | 1 Entry hole G3/4 |
| Installation Method | Wall or column platform installation |
| PTZ | |
| Rotation Angel | Horizontal:0°-360° Vertical:-90°-+90° |
| Approved | |
| Protectior | IK08(IEC 62262:IP68(IEC 60529-2013) |
| Explosion protection |
ATEX:ll 2G Ex db lIC T6 Gb/ll 2D Ex tb IIIC T80℃Db IP68 IECEx:Ex db lIC T6 Gb/Ex tblIIC T80C Db IP68;For explosive gas atmospheres,the maximum surface temperature is 85℃.Flammable dust atmosphere with a maximum surface temperature of 8°℃;IC:Explosive gas atmospheres other than mine fires;Explosive gas mixture environment:Sector 1,Sector 2,Sector 21,Sector 22. |
| Verfication to | BS EN62676-1-1-2014- Video surveillance systems for use in security applications |
Service
Use Scenarios
Explosion-Proof Surveillance in Petrochemical Industry
In petrochemical plants where explosion hazards are prevalent, the 8MP22X serves as a mission-critical surveillance security camera that continuously monitors hazardous zones without risking ignition. Its certified explosion-proof enclosure and corrosion-resistant materials comply with ATEX and IECEx regulations. The camera’s PTZ function and high-resolution imagery enable operators to inspect and manage plant perimeters, pipeline corridors, and storage tanks with precision. Integration with existing SCADA and video management systems via ONVIF ensures real-time alerts and operational continuity, making it an indispensable component for safety and compliance in industrial workflows.
Maritime and Offshore Asset Protection
Operating in harsh marine environments, the 8MP22X provides secure, reliable surveillance on oil rigs, vessels, and offshore terminals. The stainless steel anti-corrosion body withstands salt spray and extreme weather, while the explosion-proof design addresses volatile gas risks. This ptz camera enhances perimeter security, enabling detailed monitoring of critical infrastructure and personnel movements through its advanced zoom and intelligent detection functions. It integrates with maritime security networks and command centers for continuous asset protection and incident management, supporting complex operational procedures in safety-sensitive marine contexts.
What materials are used in the construction of the 8MP22X PTZ IP Camera?
Our 8MP22X PTZ IP Camera is built with corrosion-resistant stainless steel 316L housing to withstand harsh environments. This makes it ideal for industries requiring explosion-proof and durable security camera solutions with robust mechanical strength and long-term reliability.
Can you provide customized options for the PTZ camera to fit different industrial applications?
Yes, we offer ODM and OEM services for our PTZ cameras. This includes customized packaging, branding, logos, and tailored technical specifications to meet specific industrial surveillance requirements. We support small and large orders to suit your project.
What installation methods are supported for the 8MP22X Explosion Proof Camera?
The camera supports wall or column platform installations, designed for ease in hazardous and hard-to-reach locations. Our cctv supplier team can provide detailed installation guidance to ensure optimal performance and compliance with safety standards.
How do you handle shipping and delivery for industrial orders?
We cooperate with major international express companies like DHL, UPS, and FedEx to expedite delivery globally. Our logistics processes ensure secure and timely shipment of your security camera orders with tracking options for your peace of mind.
